• Support Power over Ethernet cable device for example wireless AP and IP camera.
• Support IEEE802.3af/at Standard .
• Transmission distance 250m, it can be flexible installation for wireless AP andSurveillance project.
• It will give the speed of 10Mbps at 250meter when connect IP cameras.
• Support upward port auto MDI/MDIX.
• Adopted storage forward switch system.
• Smart  power and minimum consumption，guarantee PD requirement.
• Provided With power supply circuit protection function and protection back-end device safety
• Automatically provide the adaptive device
• Fanless design realize saving energy and environment protection
• 8 10/100Mbps POE port
• 1 10/100Mbps Uplink Port
• Support saving power function when port disconnection

Specifications:

Network Interface: 8 10/100Mbps  PoE  RJ45 port  (port 1~port 8)
1 10/100/1000Mbps  Non-POE  RJ45 port (port 9)

Transmission Rate: 10/100Mbps Each port Supports MDI/MDIX auto-flip and auto-negotiation. Network interface: 10BASE-T or 100BASE-TX Ethernet  RJ-45 Port

Network Protocol and Standard: IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX ANSI/IEEE 802.3 NWay auto-negotiation IEEE 802.3x Flow Control IEEE 802.3af/at Standard

Performance: Bandwidth:1.8Gbps  (no block) Network delay (100 to 100M bps): Maximum 20μs (using 64 byte  packet) Frame filtering and transmission rate 10M:14,800pps 100M:1,48,800pps

LEDs Indicator: Power, LINK/ACT, PoE

POE Pin: 1/2(+),3/6(-);

Power: Total Power: 96W

Operating Temperature: 0°~40°C

Storage Temperature: -10℃~70℃

Operating Humidity: 10%~90% (Non-condensing)

Storage Humidity: 5%~90% (Non-condensing)

Dimensions(LxWxH): (184x94x27)mm

Weight 1.05kg
